Bohler Shallow Profile

TDS
MSDS
Guides
Bohler® Shallow Profile is a 14-tooth and HP-44 edge-hard rule with a unique gullet profile that requires minimal penetration on various substrates. While this rule cuts many materials with little impression, a uniform and leveled anvil is strongly recommended. This is also a good option for soft anvil roller diecutters and higher durometer soft anvils.

Steel rule is sold in coils for auto-benders, (wound clockwise CW or anticlockwise ACW). Also available in dispenser coils and boxed strips.
Our Customers Also Buy...
Diansuply DS-65 MicroCell Ejection Rubber
F-Bond Rotary Adhesive
Pace Serrated Tube Punches
Flat & Rotary Diemaking Tools
» See All Recommendations
Loading, please wait
SKU
Description
UM
Length
Net Wt.
Ft/Box
Qty
57764780Bohler Shallow Profile - 3PT, 14T, CF, 0.937", Straight No Notch, Fine Cut, 36"COFT36"-210
57765150Bohler Shallow Profile - 3PT, 14T, CF, 0.937", Straight No Notch, Fine Cut, Dispenser CoilFT-164
57766630Bohler Shallow Profile - 3PT, 14T, CF, 0.937", Straight No Notch, Fine Cut, EZ-Coil ACWFT-164
57767000Bohler Shallow Profile - 3PT, 14T, CF, 1", Straight No Notch, Fine Cut, EZ-Coil ACWFT-100
57768110Bohler Shallow Profile - 3PT, 14T, CF, 1.125", Straight No Notch, Fine Cut, Dispenser CoilCOFT-164
57769220Bohler Shallow Profile - 3PT, 14T, CF, 1.125", Straight No Notch, Fine Cut, EZ-Coil ACWFT-164
57769960Bohler Shallow Profile - 3PT, 14T, CF, 1.250", Straight No Notch, Fine Cut, Dispenser CoilFT-164
57770700Bohler Shallow Profile - 3PT, 14T, CF, 1.250", Straight No Notch, Fine Cut, EZ-Coil ACWFT-164
57771070Bohler Shallow Profile - 3PT, 14T, CF, 1.5", Straight No Notch, Fine Cut, 36"FT36"-164
57771440Bohler Shallow Profile - 3PT, 14T, CF, 1.5", Straight No Notch, Fine Cut, Dispenser CoilFT-164
57771810Bohler Shallow Profile - 3PT, 14T, CF, 1.5", Straight No Notch, Fine Cut, EZ-Coil ACWFT-164
57771815Bohler Shallow Profile - 3PT, 14T, CW, 1.500", Straight No Notch, Fine CutFT-164
57774400Bohler Shallow Profile - 3PT, 14T, CF, 2", Straight No Notch, HP44, EZ-Coil ACWFT-164
57772550Bohler Shallow Profile - 3PT, 14T, CF, 2", Straight No Notch, 36"FT36"-164
57774035Bohler Shallow Profile - 3PT, 14T, CF, 2.000", Titanium Coated, Dispenser CoilFT-164
57775880Bohler Shallow Profile - 4PT, 14T, CF, 0.937", Straight No Notch, Bevel Out, Dispenser CoilFT-164
57776250Bohler Shallow Profile - 4PT, 14T, CF, 0.937", Straight No Notch, Fine Cut, EZ-Coil ACWFT-164
57776620Bohler Shallow Profile - 4PT, 14T, CF, 0.990", Straight No Notch, Fine Cut, EZ-Coil ACWFT-164
57777730Bohler Shallow Profile - 4PT, 14T, CF, 1", Straight No Notch, Fine Cut, EZ-Coil ACWFT-164
57778470Bohler Shallow Profile - 4PT, 14T, CF, 1.125", Straight No Notch, Fine Cut, EZ-Coil ACWFT-164
57779580Bohler Shallow Profile - 4PT, 14T, CF, 1.250", Straight No Notch, Fine Cut, 36"FT36"-164
57778840Bohler Shallow Profile - 4PT, 14T, CF, 1.250", Straight No Notch, Fine Cut, Dispenser CoilFT-164
57779210Bohler Shallow Profile - 4PT, 14T, CF, 1.250", Straight No Notch, Fine Cut, EZ-Coil ACW (One Box/164 FT)FT-164
57779952Bohler Shallow Profile - 4PT, 14T, CF, 1.437", Straight No Notch, Fine Cut, 36"COFT36"-164
57781430Bohler Shallow Profile - 4PT, 14T, CF, 1.5", Straight No Notch, Dispenser Coil, 82FTFT-164
Showing 1 to 25 of 30 rows
2550All
rows per page
SKU Description   UM Thick Width Length Height Board ft. Diameter Grade Grit Plys Radius SPB Ship Note Min. Qty Pcs/Box Pcs/Bundle Winding Ft/Box Handle Len Head Diam Head Len Qty
